Interface |
Fixed WAN Port | 1x Gigabit Ethernet |
LAN/WAN Switchable Port | 1x Gigabit Ethernet |
Fixed LAN Port | 4x Gigabit Ethernet |
USB Port | 2x USB 2.0 for 3G/4G/LTE USB modem, storage, printer or thermometer |
Performance |
NAT Throughput | 500 Mbps |
NAT Throughput w/ Hardware Acceleration | 900 Mbps |
Max. Number of NAT Sessions | 50,000 |
Max. Concurrent VPN Tunnels | 50 |
Max. Concurrent OpenVPN + SSL VPN | 25 |
Internet Connection |
IPv4 | PPPoE, DHCP, Static IP, PPTP/L2TP |
IPv6 | PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
802.1p/q Multi-VLAN Tagging | |
Multi-VLAN/PVC | |
3G/4G/LTE WAN with USB modem | |
Load Balancing | IP-based, Session-based |
WAN Active on Demand | Link Failure, Traffic Threshold |
Connection Detection | ARP, Ping |
WAN Data Budget | |
Dynamic DNS | |
DrayDDNS | |
LAN Management |
VLAN | 802.1q Tag-based, Port-based |
Max. Number of VLAN | 16 |
Number of LAN Subnet | 8 |
DHCP Server | Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
LAN IP Alias | |
Wired 802.1x Authentication | |
Port Mirroring | |
Local DNS Server | |
Conditional DNS Forwarding | |
Hotspot Web Portal | |
Hotspot Authentication | Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server |
Networking |
Routing | IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2, BGP |
Policy-based Routing | Protocol, IP Address, Port, Domain, Country |
High Availability | |
DNS Security (DNSSEC) | |
IGMP | IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave |
Local RADIUS server | |
SMB File Sharing | (Requires external storage) |
VPN |
LAN-to-LAN | |
Teleworker-to-LAN | |
Protocols | PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN(Host to LAN) |
User Authentication | Local, RADIUS, LDAP, TACACS+, mOTP |
IKE Authentication | Pre-Shared Key, X.509 |
VPN Trunk (Redundancy) | Load Balancing, Failover |
Single-Armed VPN | |
NAT-Traversal (NAT-T) | |
DrayTek VPN Matcher | |
Firewall & Content Filtering |
NAT | Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
ALG (Application Layer Gateway) | SIP, RTSP, FTP, H.323 |
VPN Pass-Through | PPTP, L2TP, IPsec |
IP-based Firewall Policy | |
Content Filtering | Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
DoS Attack Defense | |
Spoofing Defense | |
Bandwidth Management |
IP-based Bandwidth Limit | |
IP-based Session Limit | |
QoS (Quality of Service) | TOS, DSCP, 802.1p, IP Address, Port, Application |
VoIP Prioritization | |
Management |
Local Service | HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069 |
Config File Export & Import | |
Firmware Upgrade | TFTP, HTTP, TR-069 |
2-Level Administration Privilege | |
Access Control | Access List, Brute Force Protection |
Notification Alert | SMS, E-mail |
SNMP | v1, v2c, v3 |
Syslog | |
Managed by VigorACS | |
Central VPN Management | 8 VPN |
Central AP Management | 20 VigorAP |
Central Switch Management | 10 VigorSwitch |
Physical |
Power Supply | DC 12V @ 1.3A |
Max. Power Consumption | 15.6 watts |
Dimension | 241mm x 166mm x 46mm |
Weight | 500g |
Operating Temperature | 0 to 45°C |
Storage Temperature | -25 to 70°C |
Operating Humidity (non-condensing) | 10 to 90% |
