DrayTek Vigor2915ac

Thương hiệu: DrayTek
3,090,000₫
  • 1 x cổng WAN cố định 10/100/1000Mbps Ethernet, RJ45.
  • 1 x cổng có thể chuyển đổi WAN/LAN 10/100/1000Mbps Ethernet, RJ45.
  • 3 x cổng LAN cố định 10/100/1000Mbps Ethernet, RJ45.
  • Wi-Fi AC1300 Wave 2 MU-MIMO (2.4GHz: 400Mbps, 5GHz: 867Mbps).
  • 1 x cổng USB sử dụng cho USB 3G/4G, máy in, ...
  • NAT Throughput lên đến 500Mbps, NAT sessions: 30.000, ...
  • Hỗ trợ lên đến 16 kênh VPN với 8 kênh VPN-SSL Tunnel.
  • Cân bằng tải trên nhiều đường truyền đồng thời, kiểm soát và quản lý băng thông giúp tối ưu hóa đường truyền internet.
  • Hỗ trợ IPv4 và IPv6.
  • Cho phép quản lý từ xa qua Cloud VigorACS2.

Bảo hành: 24 tháng

PHẦN CỨNG
Port
  • 2 port WAN Gigabit (10/100/1000Mbps, RJ-45).
  • WAN 2 được chuyển đổi từ LAN 4.
  • 4 port LAN Gigabit (10/100/1000Mbps, RJ-45).
  • 1 port USB 3G/4G.
Nguồn
  • Power Adapter DC 12V/1A
  • Max. Power 10 watt
Antenna
  • 2 Antena đa hướng
  • 4 dBi cho 5GHz, 2 dBi cho 2.4GHz
Nút điều khiển
  • 1 x Factory Reset Button
  • 1x Wireless On/OFF/WPS Button
Kích thước
  • 220mm x 160mm x 36mm
Trọng lượng
  • 400g (ac model)



KHÔNG DÂY
Chuẩn tương thích
  • 802.11n 2x2 MIMO 400 Mbps
  • 802.11ac 2x2 MIMO 867 Mbps
Băng tần
  • 2.4Ghz
  • 5Ghz
Tốc độ Wi-Fi
  • 400Mbps ở băng tần 2.4Ghz
  • 867Mbps ở băng tần 5Ghz
Wireless Security
  • WEP, WPA, WPA2, Mixed(WPA+WPA2), WPA3 persional
  • Pre-Shared Key, 802.1X
Tính năng Wi-Fi



  • Wireless AP
  • Wireless Client List
  • Wireless LAN Isolation
  • Wireless Wizard
  • Hidden SSID
  • WPS
  • MAC Address Access Control
  • Access Point Discovery
  • WDS (Wireless Distribution System)
  • Multiple SSID
  • SSID VLAN Grouping with LAN Port (Port-based VLAN)



PHẦN MỀM
WAN

Ethernet

  • IPv4-  DHCP Client, Static IP, PPPoE, PPTP, L2TP, 802.1p/q Multi-VLAN Tagging
  • IPv6- Tunnel Mode: PPP, TSPC, AICCU, 6in4, 6rd
               Dual Stack:DHCPv6 Client, Static IPv6, DSLite*
  • USB WAN
    • PPP
  • Outbound Policy-based Load-balance
  • WAN Connection Failover
  • 30,000 NAT Sessions
Network
  • DHCP Client/Relay/Server
  • RADVD for IPv6
  • DHCPv6 Server
  • Static IPv6 Address Configuration
  • IGMP Proxy V2/V3
  • IGMP Snooping
  • Dynamic DNS
  • NTP Client
  • RADIUS Client
  • DNS Cache/Proxy
  • UPnP 30 Sessions
  • Routing Protocol:
  • Static Routing
  • RIPv2
  • VLAN Tagging(802. 1q) on LAN*
  • Support Route Policy Function



IPv6 Network
  • PPP, DHCPv6, Static IP, TSPC, AICCU, 6rd, 6in4 Static Tunnel
Management
  • Web-based User Interface (HTTP/HTTPS)
  • Quick Start Wizard
  • CLI (Command Line Interface, T elnet/SSH)
  • Administration Access Control
  • Configuration Backup/Restore
  • Built-in Diagnostic Function
  • Firmware Upgrade via TFTP/FTP/HTTP/TR-069
  • Logging via Syslog
  • SNMP V2/V3
  • Management Session Time Out
  • Two-level Management (Admin/User Mode)
  • External Device
  • TR-069



Chất lượng dịch vụ
  • QoS :
    • Guarantee Bandwidth for V oIP (VoIP QoS)
    • Class-based Bandwidth Guarantee by User-defined Traffic Categories
    • DiffServ Code Point Classifying
    • 4-level Priority for Each Direction (Inbound/Outbound)
    • Bandwidth Borrowed
  • Bandwidth/Session Limitation
  • Layer-3 (TOS/DSCP) QoS Mapping
  • Smart Bandwidth Limitation (Triggered by Traffic/Session)



VPN
  • Offer 16 VPN Tunnels and 8 SSL VPN tunnels
  • Protocol : PPTP, IPSec, L2TP, L2TP over IPSec
  • Encryption : MPPE and Hardware-based AES/DES/3DES
  • Authentication : MD5, SHA-1
  • IKE Authentication : Pre-shared key and Digital Signature (X.509)
  • LAN-to-LAN, Host-to-LAN
  • IPsec NAT-traversal (NAT-T)
  • Dead Peer Detection (DPD)
  • VPN Backup Mode
  • DHCP over IPSec
  • VPN Pass-through
  • VPN Wizard
  • mOTP
Tính năng nâng cao

Firewall

  • Multi-NAT, DMZ Host, Port-redirection and Open Port
  • Object-based Firewall
  • MAC Address Filter
  • SPI (Stateful Packet Inspection) (Flow Track)
  • DoS/ DDoS Prevention
  • IP Address Anti-spoofing
  • E-mail Alert and Logging via Syslog
  • Bind IP to MAC Address
  • Time Schedule Control
  • User Management

CSM

  • (Content Security Management)
  • IM/P2P Application
  • GlobalView Web Content Filter (Powered by CYREN )
  • URL Content Filter :
  • URL Keyword Blocking (Whitelist and Blacklist)
    Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking,
  • Excepting Subnets
USB
  • File Sharing:
    • Support FAT32 File System
    • Support FTP Function for File Sharing
    • Support Samba for File Sharing
  • 3.5G (HSDPA)/4G (LTE)* as WAN3
