| PHẦN CỨNG |
|---|
| Port | - 2 port WAN Gigabit (10/100/1000Mbps, RJ-45).
- WAN 2 được chuyển đổi từ LAN 4.
- 4 port LAN Gigabit (10/100/1000Mbps, RJ-45).
- 1 port USB 3G/4G.
|
| Nguồn | - Power Adapter DC 12V/1A
- Max. Power 10 watt
|
| Nút điều khiển | |
| Trọng lượng | |
| PHẦN MỀM |
|---|
| WAN | Ethernet - IPv4- DHCP Client, Static IP, PPPoE, PPTP, L2TP, 802.1p/q Multi-VLAN Tagging
- IPv6- Tunnel Mode: PPP, TSPC, AICCU, 6in4, 6rd
Dual Stack:DHCPv6 Client, Static IPv6, DSLite* - USB WAN
- Outbound Policy-based Load-balance
- WAN Connection Failover
- 30,000 NAT Sessions
|
| Network | - DHCP Client/Relay/Server
- RADVD for IPv6
- DHCPv6 Server
- Static IPv6 Address Configuration
- IGMP Proxy V2/V3
- IGMP Snooping
- Dynamic DNS
- NTP Client
- RADIUS Client
- DNS Cache/Proxy
- UPnP 30 Sessions
- Routing Protocol:
- Static Routing
- RIPv2
- VLAN Tagging(802. 1q) on LAN*
- Support Route Policy Function
|
| Management | - Web-based User Interface (HTTP/HTTPS)
- Quick Start Wizard
- CLI (Command Line Interface, T elnet/SSH)
- Administration Access Control
- Configuration Backup/Restore
- Built-in Diagnostic Function
- Firmware Upgrade via TFTP/FTP/HTTP/TR-069
- Logging via Syslog
- SNMP V2/V3
- Management Session Time Out
- Two-level Management (Admin/User Mode)
- External Device
- TR-069
|
| Chất lượng dịch vụ | - QoS :
- Guarantee Bandwidth for V oIP (VoIP QoS)
- Class-based Bandwidth Guarantee by User-defined Traffic Categories
- DiffServ Code Point Classifying
- 4-level Priority for Each Direction (Inbound/Outbound)
- Bandwidth Borrowed
- Bandwidth/Session Limitation
- Layer-3 (TOS/DSCP) QoS Mapping
- Smart Bandwidth Limitation (Triggered by Traffic/Session)
|
| VPN | - Offer 16 VPN Tunnels and 8 SSL VPN tunnels
- Protocol : PPTP, IPSec, L2TP, L2TP over IPSec
- Encryption : MPPE and Hardware-based AES/DES/3DES
- Authentication : MD5, SHA-1
- IKE Authentication : Pre-shared key and Digital Signature (X.509)
- LAN-to-LAN, Host-to-LAN
- IPsec NAT-traversal (NAT-T)
- Dead Peer Detection (DPD)
- VPN Backup Mode
- DHCP over IPSec
- VPN Pass-through
- VPN Wizard
- mOTP
|
| Tính năng nâng cao | Firewall - Multi-NAT, DMZ Host, Port-redirection and Open Port
- Object-based Firewall
- MAC Address Filter
- SPI (Stateful Packet Inspection) (Flow Track)
- DoS/ DDoS Prevention
- IP Address Anti-spoofing
- E-mail Alert and Logging via Syslog
- Bind IP to MAC Address
- Time Schedule Control
- User Management
CSM - (Content Security Management)
- IM/P2P Application
- GlobalView Web Content Filter (Powered by CYREN )
- URL Content Filter :
- URL Keyword Blocking (Whitelist and Blacklist)
Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking, - Excepting Subnets
|
| USB | - File Sharing:
- Support FAT32 File System
- Support FTP Function for File Sharing
- Support Samba for File Sharing
- 3.5G (HSDPA)/4G (LTE)* as WAN3
|
