| Dimensions (L x W x H) | 9 mm x 64 mm x 165 mm |
| Scanner Weight | 160 g |
| Input Voltage | 4.4V DC – 5.5V DC |
| Operating Power (Charging) Bases | 2.5W (500 mA @ 5V DC) |
| Host System Interfaces | USB |
| User Indicators | Good Decode LEDs, Rear View LEDs, Beeper (adjustable tone and volume), Vibration (optional) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Electrostatic Discharge (ESD) (Scanners and Cradles) | -40°C to 70°C (-40°F to 158°F) |
| Electrostatic Discharge (ESD) (Scanners and Cradles) | ±8 kV indirect coupling plane, ±15 kV direct air |
| Humidity | 0% to 95% relative humidity, non-condensing |
| Tumble | 2,000 0.5 m (1.6 ft) tumbles (impacts) |
| Drop | Engineered to withstand 50 1.8 m (6 ft) drops to concrete |
| Environmental Sealing | IP41 |
| Light Levels | 0 to 100,000 lux (9,290 foot-candles) |
| Scan Pattern | Area Image (1280 x 800 pixel array) |
| Motion Tolerance | Up to 400 cm/s (157 in/s) for 13 mil UPC at optimal focus |
| Scan Angle | Horizontal: 48°; Vertical: 30° |
| Roll, Pitch, Skew | ±360°, ±45°, ±65° |
