| Port | - 24 x 10/100/1000Mbps Giga Ethernet with PoE+ PSE, RJ-45 (Each Port can Suppor t Both IEEE 802.3af / 802.3at Mode)
- 4 x Gigabit/10 Gigabit slot SFP
- 1 x Console Port, RJ45
|
| Nguồn | - Voltage: 100 ~ 240VAC
- PoE Power Budget 400 Watt
|
| Nút điều khiển | |
| Kích thước | |
| Trọng lượng | |
| PHẦN MỀM |
|---|
| Chuẩn tương thích | - IEEE 802.3 1 0Base-T
- IEEE 802.3u 1 00Base-T
- IEEE 802.3ab 1 000Base-T
- IEEE 802.3x Flow Control Capability
- ANSI/IEEE 802.3 Auto-negotiation
- IEEE 802. 1p Class of Service
- IEEE 802. 1d Spanning Tree
- IEEE 802. 1w Rapid Spanning Tree
- IEEE 802. 1s Multiple Spanning Tree
- IEEE 802.3ad P ort T runk with LACP
- IEEE 802. 1x Port Based Network Access Control
- IEEE 802. 1AB Link Layer Discovery Protocol (LLDP)
- IEEE 802. 1az Energy Efficient Ethernet
|
| Management | - Multiple User Account
Two-level Security (Admin/User) - HTTP(s) Web User Interface
- Simple Network Time Protocol
- Link Layer Discovery Protocol
LLDP-MED, Media Endpoint Discovery Extension
Simple Network Management Protocl v1/v2c/v3 - Support Generic Traps
- Command Line Interface (CLI) via T elnet/SSH
- DrayTek Switch Management
|
| Chất lượng dịch vụ | - Support 8 Queues
- Rate Limit
Port-based (Ingress/Egress) - Queue Setting
WRR
Strict Priority - Class of Service
802. 1p CoS
DSCP
CoS-DSCP
IP Precedence
|
| THÔNG SỐ KHÁC |
|---|
| Chứng chỉ | |
| Môi trường | - Temperature Operating: 0°C ~ 40°C
- Temperature Storage: -20°C ~ 70°C
- Humidity Operating: 10% ~ 90% (non-condensing)
- Humidity Storage: 5% ~ 90%(non-condensing)
|
