| Performance | |
| Buffer Size (Mbit) | 4.2 |
| Switching Capacity (Gbps) | 56 |
| Forwarding Rate (64 bytes)(Mpps) | 41.7 |
| MAC Address Table | 8K |
| Max. Jumbo Frame (KB) | 9 |
| Ports | |
| 1 GbE | 24 |
| GbE/SFP Combo | 4 |
| PoE | |
| PoE+(802.3af/at) Ports | 24 |
| PoE Power Budget (watts) | 400 |
| Scheduled On/Off | o |
| Standard Compliance | |
| Ethernet Standards | 802.3af PoE 802.3at PoE+ 802.3 10Base-T 802.3u 100Base-T 802.3ab 1000Base-T 802.1q Tag-based VLAN 802.3x Flow Control 802.3 Auto-Negotiation 802.1p Class of Service 802.1d STP 802.1w RSTP 802.3ad LACP 802.1AB LLDP 802.3az EEE |
| Spanning Tree | |
| STP | o |
| RSTP | o |
| Link Aggregation | |
| Max. Number of Group | 8 |
| Max. Number of Member in Each Group | 8 |
| Type | LACP, Static |
| Traffic Load Balancing | o |
| VLAN | |
| Max. Number of VLAN | 255 |
| VLAN Type | 802.1q Tag-based VLAN MAC-based VLAN Protocol-based VLAN Management VLAN Voice VLAN Surveillance VLAN |
| Multicast | |
| IGMP Snooping | v2, v3(BISS) |
| IGMP Querier | o |
| ONVIF Surveillance | |
| Discovery | o |
| Surveillance Topology | o |
| Real-Time Video Streaming | o |
| ONVIF Device Maintenance | Device Info Network Settings Time Settings Reboot Reset to Factory Default |
| QoS | |
| Number of QoS Queues | 8 |
| Queue Schedule | SPQ, WRR |
| CoS (Class of Service) | CoS DSCP CoS-DSCP IP Precedence |
| Rate Limiting | o |
| Security | |
| IP Source Guard | o |
| Traffic Control | DoS Defense, Storm Control |
| IP Conflict Prevention | o |
| Loop Protection | o |
| Management | |
| Local Service | HTTP HTTPS Telnet SSH v2 |
| Config Backup/Restore | o |
| 2-Level Administration Privilege | o |
| Access Control | Access List |
| OpenVPN Client | o |
| SNMP | v1, v2c, v3 |
| SNTP (Simple Network Time Protocol) | o |
| LLDP | o |
| Mail Alert | Port Status Port Speed System Restart IP Conflict Hardware Monitor Device Check ONVIF IP Cam Snapshot |
| VigorRouter Management (SWM) | o |
| VigorConnect Management (Since f/w) | V2.7.0 |
| VigorACS Management (Since f/w) | V2.7.0 |
| Physical | |
| Rack Mountable | 1U |
| Power Input | AC 100-240V @ 6.5A |
| Max. Power Consumption (watts) | 460.3 |
| Dimension (mm) | 440 x 281.3 x 44 |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 70°C |
| Operating Humidity (non-condensing) | 10 to 90% |
| Storage Humidity (non-condensing) | 5 to 90% |
